251933-YTG-J-1009
40 Johnson Controls Unitary Products
115°F 125°F
1000
77 42.1 4.3 15.8 13.7 10.1 - - - 38.5 4.7 14.4 13.1 9.6 - - -
72 38.9 4.3 23.8 20.2 16.6 13.0 - - 35.6 4.7 22.7 19.2 15.7 12.2 - -
67 35.7 4.4 31.7 26.6 23.0 19.4 15.8 - 32.7 4.7 31.1 25.3 21.8 18.3 14.8 -
62 31.9 4.3 31.9 31.9 26.4 22.8 19.2 15.6 29.6 4.7 29.6 29.6 25.1 21.6 18.0 14.5
1200
77 43.8 4.4 20.1 15.7 11.3 - - - 39.6 4.7 19.1 14.8 10.5 - - -
72 40.5 4.4 27.3 22.9 18.5 14.1 - - 36.6 4.8 25.8 21.6 17.3 13.0 - -
67 37.1 4.4 34.5 30.1 25.7 21.3 17.0 - 33.7 4.8 32.6 28.3 24.0 19.8 15.5 -
62 33.2 4.4 33.2 33.2 29.5 25.1 20.8 16.4 30.5 4.8 30.5 30.5 27.6 23.3 19.1 14.8
57 33.3 4.4 33.3 33.3 29.6 25.2 20.8 16.5 31.0 4.8 31.0 31.0 27.7 23.5 19.2 14.9
1400
77 45.5 4.4 24.3 17.7 12.5 - - - 40.7 4.8 23.8 16.5 11.5 - - -
72 42.0 4.4 30.8 25.6 20.5 15.3 - - 37.7 4.8 29.0 23.9 18.9 13.8 - -
67 38.5 4.4 37.2 33.6 28.5 23.3 18.1 - 34.6 4.9 34.1 31.3 26.3 21.2 16.2 -
62 34.5 4.4 34.5 34.5 32.6 27.5 22.3 17.2 31.4 4.9 31.4 31.4 30.2 25.1 20.1 15.1
57 34.6 4.4 34.6 34.6 32.7 27.6 22.4 17.3 32.0 4.8 32.0 32.0 30.3 25.3 20.2 15.2
1600
77 47.2 4.4 28.6 19.6 13.7 - - - 41.9 4.9 28.5 18.3 12.5 - - -
72 43.6 4.4 34.3 28.4 22.4 16.5 - - 38.7 4.9 32.1 26.3 20.5 14.7 - -
67 40.0 4.5 40.0 37.1 31.2 25.2 19.3 - 35.6 4.9 35.6 34.3 28.5 22.7 16.9 -
62 35.8 4.5 35.8 35.8 35.8 29.8 23.9 18.0 32.3 4.9 32.3 32.3 32.3 26.9 21.1 15.3
57 35.8 4.4 35.8 35.8 35.8 29.9 24.0 18.1 32.9 4.9 32.9 32.9 32.9 27.1 21.3 15.5
1800
72 43.2 4.4 36.0 29.3 22.7 16.0 - - 38.4 4.9 33.8 27.2 20.5 13.8 - -
67 39.6 4.5 39.6 38.2 31.5 24.9 18.2 - 35.3 4.9 35.3 35.2 28.5 21.8 15.1 -
62 35.5 4.5 35.5 35.5 35.5 28.8 22.2 15.5 32.1 4.9 32.1 32.1 32.1 25.6 18.9 12.2
57 35.5 4.4 35.5 35.5 35.5 28.9 22.3 15.6 32.6 4.9 32.6 32.6 32.6 25.9 19.2 12.6
2000
72 42.8 4.4 37.7 30.3 22.9 15.6 - - 38.2 4.9 35.6 28.0 20.4 12.9 - -
67 39.3 4.5 39.3 39.2 31.9 24.5 17.1 - 35.1 4.9 35.1 35.1 28.4 20.9 13.3 -
62 35.1 4.4 35.1 35.1 35.1 27.8 20.4 13.0 31.8 4.9 31.8 31.8 31.8 24.2 16.7 9.1
57 35.2 4.4 35.2 35.2 35.2 27.9 20.5 13.1 32.4 4.9 32.4 32.4 32.4 24.8 17.2 9.6
1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
XP048 (4.0 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
