251933-YTG-J-1009
Johnson Controls Unitary Products 41
XP060 (5.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1250
77 69.7 3.8 25.8 21.7 17.7 - - - 67.7 4.3 26.6 21.9 17.2 - - -
72 64.2 3.7 34.2 30.1 26.0 22.0 - - 62.6 4.3 35.2 30.6 25.9 21.2 - -
67 58.7 3.7 42.6 38.5 34.4 30.3 26.3 - 57.5 4.2 43.9 39.2 34.5 29.9 25.2 -
62 52.8 3.6 52.8 47.5 41.2 37.1 33.1 29.0 52.0 4.2 52.0 49.4 42.1 37.4 32.7 28.0
1500
77 74.1 3.8 30.6 25.3 20.0 - - - 70.7 4.3 30.5 24.9 19.2 - - -
72 68.3 3.8 40.1 34.8 29.5 24.2 - - 65.4 4.3 40.2 34.5 28.8 23.1 - -
67 62.4 3.7 49.6 44.3 39.0 33.7 28.4 - 60.1 4.2 49.9 44.2 38.5 32.8 27.1 -
62 56.2 3.7 56.2 52.6 46.8 41.5 36.2 30.9 54.4 4.2 54.4 52.6 46.9 41.2 35.5 29.9
57 54.6 3.7 54.6 54.6 49.3 44.0 38.7 33.4 53.5 4.2 53.5 53.5 48.1 42.4 36.7 31.0
1750
77 78.6 3.9 35.4 28.9 22.3 - - - 73.8 4.4 34.5 27.8 21.1 - - -
72 72.3 3.8 46.0 39.5 33.0 26.5 - - 68.2 4.3 45.2 38.5 31.8 25.1 - -
67 66.1 3.7 56.7 50.1 43.6 37.1 30.6 - 62.7 4.2 55.9 49.2 42.5 35.8 29.1 -
62 59.6 3.7 59.6 57.8 52.3 45.8 39.3 32.7 56.8 4.2 56.8 55.9 51.8 45.1 38.4 31.7
57 57.9 3.7 57.9 57.9 55.1 48.6 42.1 35.5 55.8 4.2 55.8 55.8 53.0 46.3 39.6 32.9
2000
77 83.0 3.9 40.2 32.4 24.7 - - - 76.9 4.4 38.5 30.8 23.1 - - -
72 76.4 3.8 51.9 44.2 36.4 28.7 - - 71.1 4.3 50.2 42.5 34.8 27.1 - -
67 69.9 3.7 63.7 56.0 48.2 40.5 32.7 - 65.3 4.2 61.8 54.1 46.4 38.7 31.0 -
62 62.9 3.7 62.9 62.9 57.8 50.1 42.4 34.6 59.1 4.2 59.1 59.1 56.6 48.9 41.2 33.5
57 61.2 3.7 61.2 61.2 60.9 53.2 45.4 37.7 58.1 4.2 58.1 58.1 58.0 50.3 42.5 34.8
2250
72 77.0 3.8 54.6 46.4 38.3 30.2 - - 71.7 4.3 52.8 44.7 36.6 28.5 - -
67 70.4 3.8 67.3 58.8 50.7 42.5 34.4 - 65.9 4.3 64.1 57.0 48.9 40.8 32.7 -
62 63.4 3.7 63.4 63.4 60.9 52.7 44.6 36.4 59.6 4.2 59.6 59.6 58.4 50.3 42.1 34.0
57 61.7 3.7 61.7 61.7 61.5 53.4 45.2 37.1 58.6 4.2 58.6 58.6 58.5 50.4 42.3 34.2
2500
72 77.6 3.8 57.2 48.7 40.2 31.6 - - 72.3 4.3 55.5 47.0 38.5 30.0 - -
67 70.9 3.8 70.9 61.7 53.1 44.6 36.0 - 66.4 4.3 66.4 59.9 51.4 42.9 34.4 -
62 63.9 3.7 63.9 63.9 63.9 55.3 46.8 38.2 60.1 4.2 60.1 60.1 60.1 51.6 43.1 34.6
57 62.1 3.7 62.1 62.1 62.1 53.6 45.0 36.5 59.1 4.2 59.1 59.1 59.1 50.6 42.1 33.6
95°F 105°F
1250
77 65.6 4.8 27.3 22.0 16.7 - - - 61.6 5.4 25.0 20.8 15.6 - - -
72 60.9 4.8 36.3 31.0 25.7 20.4 - - 56.8 5.4 34.5 29.3 24.2 19.0 - -
67 56.3 4.7 45.3 40.0 34.7 29.4 24.1 - 52.0 5.3 44.1 37.9 32.7 27.6 22.4 -
62 51.3 4.7 51.3 51.3 43.0 37.7 32.4 27.1 48.0 5.3 48.0 48.0 39.8 34.6 29.5 24.3
1500
77 67.3 4.8 30.5 24.4 18.3 - - - 63.1 5.4 29.1 23.1 17.1 - - -
72 62.5 4.8 40.3 34.3 28.2 22.1 - - 58.2 5.4 38.5 32.5 26.6 20.6 - -
67 57.7 4.7 50.2 44.1 38.0 31.9 25.8 - 53.3 5.3 47.9 41.9 36.0 30.0 24.0 -
62 52.6 4.7 52.6 52.6 47.1 41.0 34.9 28.8 49.2 5.3 49.2 49.2 43.7 37.8 31.8 25.8
57 52.4 4.7 52.4 52.4 46.8 40.8 34.7 28.6 49.1 5.3 49.1 49.1 43.6 37.7 31.7 25.8
1750
77 69.0 4.9 33.7 26.8 19.9 - - - 64.7 5.4 33.2 25.4 18.7 - - -
72 64.1 4.8 44.4 37.5 30.6 23.7 - - 59.6 5.4 42.5 35.7 28.9 22.2 - -
67 59.2 4.7 55.1 48.2 41.3 34.4 27.5 - 54.6 5.3 51.7 46.0 39.2 32.5 25.7 -
62 54.0 4.7 54.0 54.0 51.2 44.3 37.4 30.6 50.4 5.3 50.4 50.4 47.7 40.9 34.1 27.4
57 53.7 4.7 53.7 53.7 50.9 44.1 37.2 30.3 50.3 5.3 50.3 50.3 47.6 40.8 34.1 27.3
2000
77 70.8 4.9 36.9 29.2 21.5 - - - 66.2 5.5 37.3 27.8 20.2 - - -
72 65.8 4.8 48.4 40.8 33.1 25.4 - - 61.1 5.4 46.4 38.9 31.3 23.8 - -
67 60.7 4.7 60.0 52.3 44.6 37.0 29.3 - 55.9 5.3 55.5 50.0 42.4 34.9 27.3 -
62 55.3 4.7 55.3 55.3 55.3 47.6 40.0 32.3 51.6 5.3 51.6 51.6 51.6 44.0 36.5 29.0
57 55.1 4.7 55.1 55.1 55.0 47.3 39.7 32.0 51.5 5.3 51.5 51.5 51.5 43.9 36.4 28.9
2250
72 66.4 4.8 51.1 43.0 35.0 26.9 - - 61.7 5.4 49.6 41.5 33.4 25.3 - -
67 61.3 4.7 60.9 55.2 47.2 39.1 31.0 - 56.5 5.3 56.3 52.6 45.3 37.2 29.1 -
62 55.9 4.7 55.9 55.9 55.9 47.8 39.7 31.6 52.1 5.3 52.1 52.1 52.1 44.1 36.0 27.9
57 55.6 4.7 55.6 55.6 55.6 47.5 39.4 31.4 52.1 5.3 52.1 52.1 52.1 44.0 35.9 27.8
2500
72 67.0 4.8 53.8 45.3 36.8 28.4 - - 62.4 5.4 52.7 44.1 35.5 26.9 - -
67 61.9 4.7 61.9 58.2 49.7 41.2 32.7 - 57.1 5.3 57.1 55.3 48.1 39.5 30.9 -
62 56.4 4.7 56.4 56.4 56.4 47.9 39.4 31.0 52.7 5.3 52.7 52.7 52.7 44.1 35.5 26.9
57 56.1 4.7 56.1 56.1 56.1 47.7 39.2 30.7 52.6 5.3 52.6 52.6 52.6 44.0 35.4 26.8
