York XP048 - XP036-060 Electrical Data (Direct Drive)

251933-YTG-J-1009
74 Johnson Controls Unitary Products
XP036-060 (Direct Drive)
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
Max
Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
036
(3.0)
208-1-60 16.6 88.0 26.0 1.6 6.0 0.0
None - - - 28.4 35
E05 4.0 1 19.2 52.4 60
E07 5.6 1 26.9 62.0 70
E10 8.0 1 38.5 76.4 80
E15 11.9 2 57.2 99.9 100
E20 15.9 2 76.4 123.9 125
230-1-60 16.6 88.0 26.0 1.6 6.0 0.0
None - - - 28.4 35
E05 5.3 1 23.0 56.0 60
E07 7.5 1 32.6 67.4 70
E10 10.6 1 46.1 83.6 90
E15 15.9 2 69.1 111.2 125
E20 21.2 2 92.2 138.8 150
208-3-60 12.8 95.0 20.0 1.6 6.0 0.0
None - - - 23.6 30
E05 4.0 1 11.1 37.5 45
E07 5.6 1 15.5 43.0 50
E10 8.0 1 22.2 51.4 60
E15 11.9 2 33.0 64.9 70
E20 15.9 2 44.1 78.8 80
230-3-60 12.8 95.0 20.0 1.6 6.0 0.0
None - - - 23.6 30
E05 5.3 1 13.3 39.5 45
E07 7.5 1 18.8 46.2 50
E10 10.6 1 26.6 55.5 60
E15 15.9 2 39.9 71.4 80
E20 21.2 2 53.2 87.3 90
048
(4.0)
208-1-60 21.1 113.0 33.0 2.3 7.6 0.0
None - - - 36.3 45
E05 4.0 1 19.2 60.3 70
E07 5.6 1 26.9 69.9 80
E10 8.0 1 38.5 84.4 90
E15 11.9 2 57.2 107.8 110
E20 15.9 2 76.4 131.8 150
230-1-60 21.1 113.0 33.0 2.3 7.6 0.0
None - - - 36.3 45
E05 5.3 1 23.0 63.9 70
E07 7.5 1 32.6 75.3 80
E10 10.6 1 46.1 91.5 100
E15 15.9 2 69.1 119.1 125
E20 21.2 2 92.2 146.7 150
208-3-60 16.0 120.0 25.0 2.3 7.6 0.0
None - - - 29.9 40
E05 4.0 1 11.1 43.8 50
E07 5.6 1 15.5 49.3 60
E10 8.0 1 22.2 57.7 60
E15 11.9 2 33.0 71.2 80
E20 15.9 2 44.1 85.1 90
230-3-60 16.0 120.0 25.0 2.3 7.6 0.0
None - - - 29.9 40
E05 5.3 1 13.3 45.8 50
E07 7.5 1 18.8 52.5 60
E10 10.6 1 26.6 61.8 70
E15 15.9 2 39.9 77.7 80
E20 21.2 2 53.2 93.6 100
