York YLAA0170 Installation Operation & Maintenance

JOHNSON CONTROLS
24
FORM 150.72-ICOM6
ISSUE DATE: 12/29/2017
SECTION 2 – PRODUCT DESCRIPTION
PRODUCT IDENTIFICATION NUMBER (PIN)
TABLE 2 - COMPLETE PIN NUMBER DESCRIPTION
FEATURE
FEATURE
DESCRIPTION
OPTION OPTION DESCRIPTION
MODEL Model (PIN 1-4) YLAA
CAPACITY
Capacity
(PIN 5-8)
0058 0058
0065 0065
0070 0070
0080 0080
0081 0081
0089 0089
0092 0092
0100 0100
0101 0101
0115 0115
0120 0120
0125 0125
0136 0136
0142 0142
0150 0150
0155 0155
0156 0156
0170 0170
0175 0175
0200 0200
UNIT
Unit Designator
(PIN 9)
S Standard Efciency
H High Efciency
REF. Refrigerant (PIN 10) E R-410A
VOLTS
Voltage
(PIN 11 & 12)
17 200/3/60
28 230/3/60
40 380/3/60
46 460/3/60
50 380-415/3/50
58 575/3/60
STARTER
Starter
(PIN 13)
X Across the Line starter
T Soft Start
DESIGN
Design Series
(PIN 14)
A Design Series A (MicroChannel) Copeland Compressor
C
Design Series C (MicroChannel CE/ETL Panel) Copeland Com-
pressor
D Design Series D (MicroChannel) Bitzer Compressor
F Design Series F (MicroChannel CE/ETL Panel) Bitzer Compressor
DEV
Development Level
(PIN 15)
B Development Level B
POWER
Power Field
(PIN 16 &17)
SX SP Supply TB
SD SP NF Disconnect Switch
BC SP Circuit Breaker w/ Lockable Handle, 65kA SCWR
BX SP Circuit Breaker w/ Lockable Handle
MB MP Supply w/Ind Sys CB&L Ext Handles
TRANS
Cntrl Transformer
(PIN 18)
X No Control Transformer Required
T Control Transformer Required
Q Special Control Transformer Required
