14
2.3.6 Probe outline dimensions and weight
Net weight: 170g (R50) (C5-2Ks)
Convex array size: 148mm (L) * 53mm (W) * 26mm (thickness)
Net weight: 180g (R60) (C5-2Fs)
Linear array size: 140mm (L) * 55mm (W) * 26mm (thickness)
Net weight: 140g (L40) (L11-4Ks)
Linear array size: 140mm (L) * 41mm (W) * 26mm (thickness)
Net weight: 135g (L25) (L11-4Gs)
Slightly Convex array size: 142mm (L) * 41mm (W) * 26mm (thickness)
Net weight: 140g (R15) (C8-5Ks)
Endocavitary array size：325mm(L)*41mm(W)*26mm(thickness）
Net weight：160g (R10) (E10-4Ks)
2.4 system configuration
The system is mainly composed of main unit equipment, transduser and application
(Android/Windows platform )
The configurable probe model is:C5-2Fs(Convex array)，C5-2Ks(Convex array)，L11-
4Ks(Linear array)， L11-4Gs(Linear array)，C8-5Ks(Slightly Convex array) ，E10-
4Ks(Endocavitary array).
liquid condensation in the circuit board, there is the risk of
short circuit.
3. Do not operate the unit in an environment with flammable or
explosive liquids, vapors or gases such as oxygen or hydrogen.
Do not use the scanner in an environment containing combustible
gas, such as an anesthetic gas, hydrogen, or flammable liquid,
such as ethanol. It may cause an explosion..
A. If there are flammable substances in the environment, do
not use the scanner.
B. Use the real-time detection environment to detect flammable
substances after the system is turned on. Do not attempt to turn
off the device or unplug the power supply. First empty the air
in the area and ensure a smooth ventilation and then turn off
the power.
4. If the system fails, please do not disassemble the scanner,
please contact the service center or your sales representative.
