APPENDIX II :
GAME OSD
DISPLAY ADJUST
SELECT GAME CHANNEL
H-POSITION
V-POSITION
- 16 -
V SIZE
H SIZE
PHASE
AUTO ADJUST
RECALL
RETURN
50
SELECT GAME CHANNEL : Choose the default value of image signal. 1~200
sets. (expandable)
H-POSITION : Move the screen image left or right.
V-POSITION : Move the screen image down or up.
V SIZE : Adjust the width of vertical device in display.
H SIZE :Adjust the width of horizontal device in display. (The same as “CLOCK”
adjustment function in VGA OSD).
PHASE : Adjust the image distortion appearing as horizontal “ noise” on the screen.
AUTO ADJUST : Adjust the signal automatically.
RECALL : Return all adjustments to the original setting.
RETURN : Back to the previous menu.
1. In Game OSD, there are three items (SELECT GAME CHANNEL, V SIZE,
H SIZE) which are different from VGA OSD. Other adjustment items are all the
same as VGA OSD.
2. How to use “DISPLAY ADJUST”?
After the user adjusts the items in the DISPLAY ADJUST, next choose
“RETURN” (back to the previous menu) then choose “EXIT” the menu. The
adjustment which the user adjusts will be stored in the SELECT GAME
CHANNEL “0”. Thereafter, as long as the user powers off and restarts, it will
appear the adjustment value of SELECT GAME CHANNEL “0”. However, if
the user changes IC board and the display distorts again, the user has to
re-adjust or choose the default value of the image signal. (refer to the appendix
of signal)
