The ordering code of AI-516/AI-516P (V8.2) series instrument is made up of 9 parts. For example:
AI－516 A N X3 L3 N S4 － 24VDC – (F2)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨
It shows that the model of this instrument is AI-516, front panel dimension is A size(96×96mm), no
module is installed in MIO slot, X3 linear current output module is installed in OUTP (main output),
ALM (alarm) is L3 (dual relay contact output module), no module is installed in AUX (auxiliary
output), S4 (RS485 communication interface module) is installed at COMM , and the power supply
of the instrument is 24VDC, an extended input type (F2 radiation type
pyrometer) is available
The following is the meanings of the 9 parts:
①
Shows the model of the instrument
AI-516 Economical type instrument with measurement accuracy 0.3%F.S. It adopts
artificial intelligent control technology, and has the functions of control, alarm, retransmission and
communication.
AI-516P Base on AI-516 added 30 segments programmable functions.
②
Shows the front panel dimension
A(A2) Front panel 96×96mm(width×height), cut out 92×92mm, depth behind mounting
surface 100mm.
A2 has a light bar with 25 segments and 4 levels of luminosity.
B Front panel 160×80mm(width×height), cut out 152×76mm, depth behind mounting surface
100mm.
C(C3) Front panel 80×160mm(width×height), cut out 76×152mm, depth behind mounting
surface 100mm.
C3 has an additional light bar with 50 segments and 2 levels of luminosity.
D Front panel 72×72mm(width×height), cut out 68×68mm, depth behind mounting surface
95mm
D2 Front panel 48×48mm(width×height), cut out 45×45mm, depth behind mounting surface
95mm
D6 Front panel 48×48mm(width×height), cut out 45×45mm, depth behind mounting surface
95mm
E(E2) Front panel 48×96mm(width×height), cut out 45×92mm, depth behind mounting surface
100mm
E2 has an additional light bar with 25 segments and 4 levels of luminosity.
F Front panel 96×48mm(width×height), cut out 92×45mm, depth behind mounting surface
100mm
E5 Rail mounted 48×96×110mm(width×height×depth), installed on DIN trail and programmed
by external display E8
③
Shows the module type of multiple functions I/O (MIO). Selectable modules are I2, I4, K3
