YUNEEC Typhoon H - Team Mode Flight Controls; ST12 Pilot Controls; Wizard Pilot Controls; ST16 Camera Operator Controls

12
FLIGHT CONTROLS (TEAM MODE)
25
27
28
29
30
31
32
26
Motor Start/Stop Buon
Landing Gear Switch
Rudder/Yaw Control (for Mode 2 and Mode 1)
Throle/Altude Control (for Mode 2)
Elevator/Pitch Control (for Mode 1)
Flight Mode Selecon Switch
GPS Knob
Proporonal Control Rate Slider
Aileron/Roll Control (for Mode 2 and Mode 1)
Elevator/Pitch Control (for Mode 2)
Throle/Altude Control (for Mode 1)
Power Switch
01
02
03
04
05
06
07
08
09
10
02
07
03
04
08
09
10
01
05
06
11
12
13
15
17
14
16
24
18
20
19
21
22
23
PILOT ST12 PILOT WIZARD™
CAMERA OPERATOR ST16
Aircra Mode LED
Wizard™ GPS LED
Aircra Status LED
Turn / Fly to the Le Side Buon
Ascend / Forward Buon
Magic Buon
Turn / Fly to the Right Side Buon
Descend / Backward Buon
Tilt Control Buon-down
Tilt Control Buon-up
Start / Stop Motors Buon
Wizard™ Power Buon
Wizard™ Power LED
Smart / Angle / Home Mode Switch
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Pan Mode：
- Follow
(yaw can’t be controlled)
- Follow Controllable
- Global
Gimbal Tilt Slider in Angle
Tilt Mode:
-Angle
-Velocity
Gimbal Tilt Control in Velocity Mode (Mode 1)
Take Sll Photo Buon
Gimbal Pan Control in Global
Follow Controllable mode
Tilt Control in Velocity (mode 2)
Start/Stop Video Recording Button
25
26
27
28
29
30
31
32
