YUNEEC Typhoon H - Specifications; Typhoon H and Camera Specifications; Ground Stations and Controllers Specifications

3
SPECIFICTATIONS
Flight Time
Size
Takeoff Weight
Battery
Battery Capacity/Voltage
Charger
Transmitter
Maximum Flying Height
Up to 25 min
20.5x18x12.2 in (520x457x310mm)
68.8oz (1950g )
4S 14.8V LiPo Battery (POWER 4)
5400mAh 4S/14.8V（79.9Wh）
SC4000-4
ST16 Personal Ground Station
122m (400ft)(Restricted by FAA)
TYPHOON H SPECIFICATIONS
Maximum Rotation Rate
Maximum Roll Angle
Maximum Climbing Speed
Maximum Speed In Angle Mode
Maximum Descending Speed
Diagonal Wheelbase
Frame Arm Length
Landing Gear Size
85°/s
35°
5m/s
13.5m/s
3m/s
18.9 in (480mm )
7.4 in (187mm)
10.4x7.3 in (265x185mm)
Weight
Effective Pixels
Camera lens
FOV
9.0oz (255g)
12.4 Megapixels
14mm/F2.8 35mm
98 °
CGO3+（CGO3 PLUS) SPECIFICATIONS
Electronic Shutter
Video Transmission Range
Transmission System
Video UHD
1/30--------1/8000s
Up to 1 Mile (1.6km)
5.2Ghz — 5.8Ghz
4K 30FPS
Operating System:
Number of Channels:
Control Transmission Distance/Range:
Video Link Frequency Band:
Android™
16
Up to 1 Mile (1.6km) (Optimum Conditions)
5.8GHz WiFi
ST16 GROUND STATION
Video Transmission Distance/Range
(Optimum Conditions):
LCD Screen Size:
Built-In Li-ion Battery Voltage / Capacity:
FCC Compliance: Up to 1 Mile (1.6km)
CE Compliance: Up to 1 Mile (1.6km)
7”
3.6V 8700mAh 31.32Wh Li-ion
Operating System:
Number of Channels:
Control Transmission Distance/Range:
Video Link Frequency Band:
Android 4.0.3
12
1000m
5.8GHz
ST12 GROUND STATION
Video Transmission Distance/Range
(Optimum Conditions):
LCD Screen Size:
Built-In Li-ion Battery Voltage / Capacity:
FCC:up to 600m;
CE:up to 300m
5.5"
5200mAh 3.6V 18.72Wh Li-ion
Dimensions
Water Resistant
5.47 X 1.46 X 0.98 in (139 X 37 X 25 mm)
Yes
WIZARD™ REMOTE CONTROLLER
Working Hours
Built-In LiPo Battery Voltage / Capacity
3.5 h
3.7V 500mAh
