7
Specifications
Power per Channel - 4 channel mode T.H.D. +N
30 watts x 4 @ 4Ω
<.02%
60 watts x 4 @ 2Ω
<.04%
100 watts x 4 @ 1Ω
<.3%
Power - Dual bridged mono
120 watts x 2 @ 4Ω
<.04%
200 watts x 2 @2Ω
<.3%
Frequency Response 20Hz - 20kHz +0, - .35dB
S/N Ratio @ 1kHz > 100dB
Transient Distortion <.016%
Slew Rate
> 40v/µS
Separation @ 1kHz, Front or Rear > 70dB
Damping Factor @ 1kHz
> 490 @ 4Ω, 230 @ 2Ω
Input Sensitivity 500mv - 5 volts
Max. Current Requirements 37 amperes @ 260 watts
Idle Current 1.65 amperes
Dimensions 7.5” x 14” x 2.5”
Power per channel vs. Distortion, four
channels driven
