Zapi ACE2 User Manual

AF2ZP0CL - ACE2 - User Manual Page - 51/85
17) CUTBACK SPEED 1
Speed reduction when the cutback input is active.
18) BACKING SPEED
It determines the speed in inching function.
19) BACKING TIME
It determines the time of the inching function.
20) FREQUENCY CREEP
Minimum speed when the forward or reverse switch is closed, but the
accelerator is on a minimum position.
21) MAXIMUM CURRENT
This parameter changes the maximum current of the inverter.
22) BRK SMOOTH
It gives a parabolic form to the deceleration ramp.
23) STOP BRK SMOOTH
Hz. It sets the level of frequency where the smooth effect of the deceleration
parabolic form ends.
24) CURVE CUTBACK
Determines the speed reduction in curve (only if the EPS is present).
25) STEER DEAD ANGLE
Under this angle the curve cutback is not applied (only if the EPS is present).
26) AUXILIARY TIME
Time units value (seconds). For the encoder version, it determines the time
duration the truck is hold on the ramp if the STOP ON RAMP option is ON.
The following table shows the minimum / maximum programmable value for
each parameter. In the table is also present the parameters resolution.
PARAMETER UNIT MIN VALUE MAX VALUE RESOLUTION
ACCELERATION 0 (*) Sec. 0,3 10 0,1
INV. ACCEL 0 (*) Sec. 0,3 10 0,1
ACCELERATION 1 (*) Sec. 0,3 10 0,1
ACCELERATION 2 (*) Sec. 0,3 10 0,1
ACCELERATION 3 (*) Sec. 0,3 10 0,1
ACC PROF. FREQ 1 Hz 0 200 1
ACC PROF. FREQ 2 Hz 0 200 1
ACC PROF. FREQ 3 Hz 0 200 1
RELEASE BRAKING (**) Sec. 0,3 10 0,1
INVERS BRAKING (**) Sec. 0,3 10 0,1
DECELERATION BRAKING (**) Sec. 0,3 10 0,1
PEDAL BRAKING (**) Sec. 0,3 10 0,1
SPEED LIMIT BRAKING (**) Sec. 0,3 10 0,1
