H2B USER'S MANUAL - 550145G Page 19/60
HANDLE / SEAT SW. 2ND SPEED SWITCH
BATTERY VOLTAGE 3RD SPEED SWITCH
FORWARD SWITCH 4TH SPEED SWITCH
BACKWARD SWITCH HYDRO SPEED REQ
BATTERY CHARGE (*) BATTERY CHARGE (*)
BACKING ENABLE (*)
QUICK INVERSION (*)
SPEED REFERENCE (*)
SPEED VALUE (*)
- SAVE: Chopper parameters are stored in the console memory.
10 different memories are available for each chopper model.
- RESTORE: Transfer of parameters from console memory to chopper memory.
10 different memories are available for each chopper model.
- ALARM: Display of in-chopper memory alarms.
- PROGRAM VACC: Potentiometer stroke parameter.
(*) H2G software only.
