ZAPTEC HOME User Manual

7
EN
ZAPTEC HOME
Status Indicators
The status of the charging station is shown by the status indicator (Z) using the following colours:
Authentication OK (once every 30 seconds means
that the charging station is ofine)
Charging complete
FlashingContinuous
Charging
2 ashes = Authentication failed
The light is off but ashes once every 30 seconds
= the charging station has not been activated in
ZAPTEC Portal. See the Troubleshooting section for
further details.
Error (see the Troubleshooting
section for further details)
Colour
BLUE
RED
YELLOW
GREEN
Connected to a vehicle and
ready to charge
System starting up
Awaiting authentication
Awaiting ZAPTEC Portal
Vehicle added to queue
Status indicator (Z)
RFID zone
Electrical outlet
IEC62196-1/2, Mode 3 Type 2
Protective cover
Open the front cover here
SmartKey
PURPLE
Firmware updating
SmartKey Column
WHITE
Clear
