CC600/CC6000 Customer Concierge Quick Start Guide
6
Setup
Perform this procedure to start using the device for the first time.
• Install a micro secure digital (SD) card (optional).
• Connect the power supply to power on the device.
• Configure the device.
• Mount the device with the mounting bracket.
Inserting the microSD Card (Optional)
The microSD card slot provides secondary non-volatile storage. The slot is located on the back of the device to the
right of the audio jack. Refer to the documentation provided with the card for more information, and follow the
manufacturer’s recommendations for use.
CAUTION:Follow proper electrostatic discharge (ESD) precautions to avoid damaging the microSD card. Proper ESD
precautions include, but are not limited to, working on an ESD mat and ensuring that the operator is properly
grounded.
To install the microSD card:
• Remove the device from the mounting bracket, if installed.
• Slide the microSD card, connectors down, into the device as shown in Figure 9.
Figure 9 Inserting microSD Card
Mounting the Device
Each configuration of the device requires the appropriate mounting bracket to mount the device to a wall or other
flat surface. The diameter of the holes for the wall screws is 5.8mm (0.228 in).
NOTE: Device measurements in Figure 10, Figure 11 and Figure 12 are in millimeters.
