Zebra DS2208 User Manual

10 DS2208 Digital Scanner Quick Start Guide
Troubleshooting
Aiming line does not appear
No power to scanner Connect scanner to powered host, or connect power supply
Aiming line is disabled Enable aiming line
Scanner decodes bar code but does not transmit data
Interface cable is loose Reconnect the cable
Transmission or format error Set the proper communication and conversion parameters
Invalid ADF rule Program the correct ADF rules
Scanner does not decode bar code
Scanner not programmed for bar code type Enable that bar code type
Bar code is unreadable Ensure the bar code is not defaced; scan a test bar code of the same
bar code type
Bar code is out of aiming line area Move the aiming line over the bar code
Scanned data incorrectly displayed on host
Host interface not configured properly Scan appropriate host parameter bar codes
Region improperly configured Select appropriate country and language encoding scheme

Zebra DS2208 Specifications

General

Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Connectivity technology	Wired
Certification	EN 60950-1 2ed + A11 + A1 + A12 + A2:2013, IEC 60950-1 2ed + A1 + A2, UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07 IEC 62471 EN 55022 (Class B); EN 55032 (Class B) EN 55024 EN 61000-3-2 EN 61000-3-3 47 CFR Part 15, Subpart B, Class B ICES-003 Issue 6, Class B
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS
Cables included	Micro-USB
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery life	100 h
Battery capacity	2400 mAh
Power consumption	250 mA
Power source type	DC
AC adapter output voltage	5 V
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	99 mm
Width	66 mm
Height	165 mm
Weight	161.6 g
