Zebra DS6878 User Manual

ZEBRA TECHNOLOGIES
5
INSTRUCTION GUIDE
PAIRING THE DS6878 TO A TABLET
The device is now connected to the iPad as a
keyboard device. Test it in an application that
accepts keyboard input, such as Notes.
7
Tap the white + in the upper
right to start a new Note.
8
Scan a barcode. It is displayed in the Note:
9
A quick double-pull of the scanner trigger will
open or close the virtual keyboard.
10
DS6878 2D IMAGER
PAIRING THE DS6878 TO IOS

Zebra DS6878 Specifications

General

Wavelength	655 nm
Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	1D, 2D, PDF417, PDF417, microPDF417, Composite Codes (CC-A, CC-B, CC-C), U.S. Postnet and Planet, U.K., Japan, Australian, Netherlands KIX code, Royal Mail 4 State Customer, UPU ICS 4 State Postal, USPS 4CB, TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse and Micro)
Tilt reading angle	-360 - 360 °
Input voltage	5 V
Bluetooth	Yes
Dimensions (WxDxH)	69 x 97 x 185 mm
Certification	FCC, RoHS
Product color	Black
International Protection (IP) code	IP43
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Cables included	USB

Weight and Dimensions

Weight	238 g
