DS9908 Hands-Free Imaging Scanner Quick Start Guide
9
Keyboard Wedge
The digital scanner automatically detects the host interface type and uses the default setting. If the default (*) does
not meet your requirements, scan the IBM PC/AT and IBM PC COMPATIBLE barcode below.
Set Defaults
Return to Factory Defaults
Add a Tab Key
To add a Tab key after scanned data, scan the barcode below.
Add a Tab Key
*IBM AT Notebook
IBM PC/AT & IBM PC Compatibles

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
