Zebra HC100 Maintenance Manual

Master Assembly Drawing
Master Assembly Drawing
16
61311L-001 Rev. A HC100 Maintenance Manual 5/8/08
Master Assembly Drawing
All information provided in Table 1 corresponds to the numbers shown in Figure 2. For
example, arrow 8 in the drawing is identifying the Main Logic Board assembly. According to
Table 1, Item 8 gives both, the name and the part number, for the kit assembly.
Maintenance Kits
Table 1 • Master Assembly Kits
Item
Kit Part Number
Assembly Name
1
61340M 61340M Upper Print Mechanism Cover Assembly
Maintenance Kit on page 99
2
61330M 61330M Printhead Assembly Maintenance Kit
on page 20
3
61331M 61331M Platen Roller Assembly Maintenance Kit
on page 30
4
61341M 61341M Print Mechanism Chassis Assembly
Maintenance Kit on page 112
5
61342M 61342M Main Frame Assembly Kit on page 129
6
61338M 61338M ZebraNet™ 10/100 Print Server Assembly
Maintenance Kit on page 77
7
61337M 61337M ZebraNet™ Internal Wireless Plus Print
Server Assembly Kit on page 59
8
61335M 61335M Main Logic Board Maintenance Kit
on page 40
61336M
9
61339M 61339M Smart Card Reader Board Maintenance Kit
on page 88
10
61343M 61343M Outer Enclosure and Trim Maintenance Kit
on page 152
Important • The printer base is not included in any kit and thus, appears gray in Figure 2.
