Zebra P110i Service Manual

980584-001 Rev. A Zebra P110i / P110m / P120i Card Printers Service Manual 1
1
General Description
1.1 Description
This manual contains service information for Zebra P110i, P110m, and P120i Plastic Card
Printers, manufactured by Zebra Technologies Corporation, Camarillo, California.
The only difference between these models is as follows:
• The P110i supports single-sided, full-color or monochrome printing.
• The P110m supports single-sided, monochrome printing only.
•The P120i supports single- or dual-sided, full-color or monochrome printing.
In this manual, references that are specific to a particular model will be identified as such;
references that apply to all three models will use the term “the printer.”
The printers provides full color dye sublimation or monochrome thermal transfer printing on
standard 2.125 inch by 3.375 inch (54 mm by 86 mm), PVC or PVC Composite plastic cards.
The integrated card feeder and flipper (P120i only) minimizes printer size while
maximizing performance.
Load-N-Go™ ribbon cartridges are used with an integrated card cleaning roller for easy
ribbon changing or replacement.
A variety of options (some of which can be factory-installed or field-installed as upgrades) are
available, making the printers configurable for varied application environments:
• Magnetic stripe encoder option
•CardSense
TM
single-card feed option
• USB or USB and Ethernet interface option
Its auto-switching 100 ~ 240 Volts AC, 50 ~ 60 Hz external power supply uses interchangeable
power cords for maximum flexibility.

Zebra P110i Specifications

General

USB 1.1 ports quantity	1
Weight (imperial)	10 lbs
Dimensions (WxDxH)	201 x 328 x 235 mm
Storage temperature (T-T)	23 - 158 °F
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
Power requirements	100 ~ 240 Volts AC, 50 ~ 60 Hz
Certification	FCC Class A CE UL CUL

Weight and Dimensions

Weight	4500 g
