Zebra P4T Maintenance Manual

• 2-15 • RMAN-P4T-001 rev. A • P4T/RP4T Repair Procedures
Section 2: Replacement Procedures
Make use of the following tools and supplies for maintaining the printer and
installing the repair kits:
Hand Tools
• #0 or #1 Phillips Head Screw Driver
• 3/32” hex driver
Supplies
• Cleaning Pen, 12 pack, p/n AN11209-1
• Isopropyl alcohol
• Spares Kit AN16753-029, consisting of:
• Eye Sensor Calibration Swatch p/n AA15417-1
• Gap Sensor Calibration Swatch p/n AA15417-2
• Media, Batteries, and Chargers for P4T series printers per table below:
Mobile Printer
Model #
Journal Media
(for Life Test)
Label Media
(for Gap test)
Label Media
Battery
Replacement Kit
SingleCharger /
Quad Charger
P4T LD-D4FN6K LD-D4YL5K LD-R4LFSP AK18913-001
AT17696-x/
AC18177-6
Storage and Handling
Tools and Supplies
The use of an ESD wrist strap at a properly grounded workstation is required
when handling printed circuit boards or other sensitive electronic components.
The ESD strap prevents any electrostatic damage to occur while assembling these
components. The use of the ESD strap will be noted in the applicable instructions.
This symbol indicates that the operator must wear a properly grounded ESD strap
to perform the repair procedure.
Storage
Replacement kits which are sensitive to ESD damage are supplied in static
resistant packaging. Always keep these parts in their original packaging until they
are to be installed.
Handling

Zebra P4T Specifications

General

Color	No
Maximum resolution	203 x 203 DPI
Core diameter	19 mm
Ribbon length	29992.3 m
Media thickness	0.08 - 0.22 mm
Maximum roll diameter	66 mm
Media thickness (imperial)	0.0032 - 0.0085 \
Bluetooth	Yes
Connectivity technology	Wireless
Battery capacity	4200 mAh
Weight (imperial)	2.9 lbs
Dimensions (WxDxH)	165.9 x 85.9 x 220.5 mm
Flash memory	8 MB
Internal memory	16 MB
Built-in barcodes	Code 39, Code 93, MaxiCode, QR Code, UPC-A, UPC-E
Page description languages	CPCL-native, EPL, EPL2, XML, ZPL
Storage temperature (T-T)	-22 - 149 °F
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Package weight	1900 g
