Zebra P4T Maintenance Manual

RMAN-P4T-001 rev. A • Introduction • -1-6 •
RFID encoded information can be retrieved using an RFID scanner from a
distance of inches to several yards from an encoded label.
Zebra’s implementation of RFID follows accepted industry standards. As an
example, the RP4T verifies the information encoded on the label media after
it is transmitted and voids the label if the data is incorrect. More information
concerning RFID may be found in Zebra’s RFID Programming Manual, available for
download on Zebra’s Web site.
Communications
Communications between the P4T/RP4T series printers and a host terminal can
occur in three basic ways:
• By a cable between the printer and its host terminal using either RS-232C serial
or USB protocols.
• By means of a Bluetooth
®
short range radio frequency link.
• By means of a wireless LAN (Local Area Network) per 802.11 specifications.
User Guide
Use of this manual presumes a familiarity with the P4T/RP4T series printers.
Complete information regarding the operation, features and specifications of the
P4T/RP4T series printers can be found in the RW Series User Guide which can be
found on-line at www.zebra.com/manuals.

Zebra P4T Specifications

General

Color	No
Maximum resolution	203 x 203 DPI
Core diameter	19 mm
Ribbon length	29992.3 m
Media thickness	0.08 - 0.22 mm
Maximum roll diameter	66 mm
Media thickness (imperial)	0.0032 - 0.0085 \
Bluetooth	Yes
Connectivity technology	Wireless
Battery capacity	4200 mAh
Weight (imperial)	2.9 lbs
Dimensions (WxDxH)	165.9 x 85.9 x 220.5 mm
Flash memory	8 MB
Internal memory	16 MB
Built-in barcodes	Code 39, Code 93, MaxiCode, QR Code, UPC-A, UPC-E
Page description languages	CPCL-native, EPL, EPL2, XML, ZPL
Storage temperature (T-T)	-22 - 149 °F
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Package weight	1900 g
