S600 Parts Catalog
Electronics
Item
Number
Description Part Number
Kit
Quantity
1 Kit Main Logic Board (includes ground bezel) S600 45763-001M 1
2 Ground Bezel 45960 1
Kit 8MB Flash RTC 44815M 1
4MB Flash Memory Upgrade 44867 1
6

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra S600 and is the answer not in the manual?

Zebra S600 Specifications

General IconGeneral
Resolution203 dpi (8 dots/mm)
Print MethodThermal Transfer
Print Speed6 ips
Maximum Print Width4.09 inches (104 mm)
Maximum Print Length39 inches
Media Length0.25 to 39 inches (6 to 991 mm)
Ribbon Length984' (300 m)
ConnectivityRS-232, Centronics Parallel
Power Requirements100-240 VAC, 50/60 Hz
