Zebra Stripe - Logic Board and Control Panel

Page 7-4
44868L
PRINTER MODEL: STRIPE
Logic Board and Control Panel
PART NUMBER DESCRIPTION QUANTITY
01155 Washer, Lock
2
01159 Washer, Lock, Star
1
09367 Hex Stand Off
2
40193 Washer, Flat
1
44053 Screw, M3.5 w/SEMS
1
44072-1 Cover, Control Panel (non-cutter)
1
44072-7 Cover, Control Panel (with Cutter)
1
44095 Sensor Arm, Head Open
1
44114 Screw, M4.2 x 1.41 x 8 Hi-Lo Hex/Phillips
5
44126-1 Bezel, Ground (Parallel)
1
44135M Media Sensor Replacement Kit
1
44272 Bezel, Ground (Serial)
1
44387 Screws w/ SEMS for Parallel units
1
44505M Control Panel
1
44537 Flat jumper, 2.9 X 1.9
1
44540 Spacer
1
44649 Stripe Main Logic to Sensor Connection
1
44670M Main Logic Board (44530M) & Media
Sensor (44135M) Replacement
Maintenance Kit
1
44716M Main Logic Board (S-300 Serial)
1
44717M Main Logic Board (S-500 Parallel)
1
44718M Main Logic Board (S-500 Parallel)
(with Battery Backed-up RAM)
1
44719M Main Logic Board (S-500 Serial)
For printers up to S/N 500762, order Part
44670M.
1
44721M Main Logic Board (S-500 Serial)
(with Battery Backed-up RAM)
1
Drawings and Parts Lists Stripe Maintenance Manual: Volume 1
