Printer Features
What are the dimensions of the printer?
Closed - 11” H x 9.5” W x 16.76” D
Open - 17.5” H x 9.5” W x 16.76” D
What accessories are available for the ZT200 series?
The ZT200 series accessories include:
Cutter
Dispenser (peeler)
Liner take up (only available on the ZT230)
What are the connectivity options?
All printers come standard with serial and USB 2.0. Optional are Centronix parallel, 10/100 Ethernet,
and 802.11 a/b/g/n wireless. Only one of the optional connectivity types (parallel, Ethernet or wireless)
can be installed in the printer at one time due to the single card slot.
How much memory is standard on the ZT200 series printers?
The ZT200 series printers have 128MB SDRAM and 128MB Flash as standard.
What is the maximum media size the ZT200 series supports?
The ZT200 series can support media widths up to 4.09” (104mm) and maximum label length of up to 39”
(xxx mm). The media core is 1” – 3” (25mm – 76mm).
Can the same ribbon and media used for the S4M and Stripe printers be
used in the ZT200 series?
Yes, but the ZT220 can only accommodate a 300M ribbon.
Can non-Zebra ribbon and media be used in the ZT200 series?
Yes, as long as the size requirements are met. Always recommend genuine Zebra supplies due to
potential quality issues with non-Zebra ribbon and media. Poor quality ribbon will shorten print head
life and impact print quality.
