Zebra ZXP Series 1 User Manual

1: Getting Started
Multi-Function LCD Panel
P1060728-002 Zebra ZXP Series 1 Card Printer User’s Manual 5
Multi-Function LCD Panel
Your printer is equipped with a Multi-Function LCD Panel to provide printer status
information. The readout is controlled by the Multi-Function Control Button directly below
the viewing window.
Multi-Function LCD Panel messages fall into three categories: Operational, Warning,
and Error.
Operational Messages
Operational Messages are displayed during the Printer’s normal operation.
OPERATIONAL
CARD READY
CLEANING PRINTER
CLOSE FEEDER DOOR
DOWNLOADING DATA
DOWNLOADING FIRMWARE
EMPTY FEEDER THEN CLOSE COVER
FEED LONG CLEANING CARD IN EXIT
INITIALIZING
INSERT CARD
INSERT FEEDER CLEANING CARD
MAG ENCODING
PRINTING BLACK
PRINTING CYAN
PRINTING MAGENTA
PRINTING MONO
PRINTING OVERLAY
PRINTING YELLOW
PUSH BUTTON TO CONTINUE
READY
REMOVE FEEDER CLEANING CARD
REMOVE LONG CLEANING CARD
REMOVE RIBBON THEN CLOSE LID
SINGLE CARD READY-PRINT OR EJECT

Zebra ZXP Series 1 Specifications

General

Interface	USB
Print Technology	Dye-sublimation
Image Quality	300 dpi
Card Sizes	CR-80 (85.6mm x 54mm)
Connectivity	USB
Print Resolution	300 dpi
Card Capacity	100-card input hopper
Power Requirements	100-240V AC, 50-60 Hz
Operating Humidity	20% to 80% non-condensing
