BOTTOM connection:
LED-STRIP
5V
GND
LED-STRIP
5V
5V
BUZZER-
UART3-TX
VTX
VOLTAGE
GND
LED-STRIP
LED-STRIP
5V
5V
5V
GND
GND
GND
5V-OUT
FROM-VTX
VIDEO
VIDEO OUT
TO VTX
GND
GND
UART4-TX
UART4-RX
ESC-TELEMETRY
CURRENT
SENSOR
(UART1-RX)
VBAT+
GND
M1
M2
M3
M4
⑷
