3 System Overview
System GOM Scan 1
Measuring points
per individual
scan
approx. 6,000,000 points
Dimensions (in mm): 290 x 215 x 80
Measuring volume (in mm):
GOM Scan 1 (100) GOM Scan 1 (200) GOM Scan 1 (400)
100 x 65 x 70 200 x 125 x 150 400 x 250 x 300
Tab. 1: GOM Scan 1
System GOM Scan 1
Transfer of image and control signals
via Gigabit Ethernet data link with a
USB interface
Projector light
Artificial optical radiation, blue (440–
465 nm)
(Medium risk according to
DIN EN 62471, issue March 2009, con‐
dition: when looking into the light
source)
Ambient conditions 0°C to +40°C (non-condensing)
Weight 2.5 kg
Voltage range (typical) 100 to 240 V, 50 to 60 Hz
Power consumption Typically 45 W
Power Factor Correction ≥ 85%
Max. cable length between sensor
and PC, laptop
5 m
Application software GOM Inspect
For more information, visit https://www.gom.com.
Tab. 2: GOM Scan 1, general data
0000002121_003_EN_01-09-2021
Page 9 (24)
