000000Ć1150Ć839 IOLMaster 11.02.2004
Spectral irradiance
spectral irradiance (white LED) in optical axis (0) and in 33 Ćdirection
wavelength in nm
300
0
0,02
0,04
0,06
0,08
0,1
0,12
350
400 450
500 550
600 650
700 750
800 850 900
 - Emission 33 - (Ee = 0,814 mW/cm
2
)
 - Emission 0 - (Ee = 0,91 mW/cm
2
)


"Optical axis" or "0" corresponds to the direct view into the illuminating projector;
33 is the angle for the intended use in anterior-chamber depth measurement.
Spectrally assessed photochemical radiation densities
photochemical radiation density of slit illumination (white LED) for phacic eyes
L
B
= 122,8 W/(m
2
sr)
wavelength in nm
300 350 400 450 500 550 600 650 700
4
3,5
3
2,5
2
1,5
1
0,5
0
Technical Data
