23
HDS4x2 User Guide, Rev 1.1, 08-31-07
IR Jack, IR Format and IR Codes
Remote IR codes (generated by the ZRM2) (continued)
Index Hex Code Key Function
25 807EC03F
1 ►1
Map input 1 to zone 1
26 807EE01F
2 ►1
Map input 2 to zone 1
27 807ED02F
3 ►1
Map input 3 to zone 1
28 807EF00F
4 ►1
Map input 4 to zone 1
29 807EC837
5 ►1
Unused
30 807EE817
6 ►1
Unused
31 807ED827
7 ►1
Unused
32 807EF807
8 ►1
Unused
33 807E02FD
1 ►2
Map input 1 to zone 2
34 807E22DD
2 ►2
Map input 2 to zone 2
35 807E12ED
3 ►2
Map input 3 to zone 2
36 807E32CD
4 ►2
Map input 4 to zone 2
37 807E0AF5
5 ►2
Map input 1 to Zones 1 & 2
38 807E2AD5
6 ►2
Map input 2 to Zones 1 & 2
39 807E1AE5
7 ►2
Map input 3 to Zones 1 & 2
40 807E3AC5
8 ►2
Map input 4 to Zones 1 & 2
41 807E827D
A
User dened discrete preset
42 807EA25D
B
User dened discrete preset
43 807E926D
C
User dened discrete preset
44 807EB24D
D
User dened discrete preset
45 807E8A75
E
User dened discrete preset
46 807EAA55
F
User dened discrete preset
47 807E9A65
G
User dened discrete preset
48 807EBA45
H
User dened discrete preset
