Zeliox ECO - Page 19

19
Connection
port
silkscreen
Connector name
Pictures
Recommended cable specifications
Polarity
Wire
diameter
Length
Color
*M12-100/P
COM
Standard network
cable
--
--
≤9m
Black
*M12-200/H
COM
MPPT COM
Standard network
cable
--
--
≤9m
Black
Data Logger
Standard network
cable
--
--
≤9m
Black
Dry contact
1
PLTB1.5-07-BF-
3.81,Green
NO/C/N
C
0.3~1.5mm
2
(16~22
AWG)
≤9m
--
Dry contact
2
PLTB1.5-07-BF-
3.81,Green
NO/C/N
C
0.3~1.5mm
2
(16~22
AWG)
≤9m
--
Dry contact
3
NO/C/N
C
0.3~1.5mm
2
(16~22
AWG)
≤9m
--
*：If there is an expanded battery, you need to prepare the corresponding
cable
Table 3-2 Harness preparation
