Figure 2-4 Interface definition

Table 2-1 Interface definition from figure 2-4

2.4 Interface definition

Silk screen

Definition

Description

①

RUN

System running

indicator

See 2.4.3 for details

②

ALARM

Fault indicator

③

SOC indicator

④

1600VA/1.28kWh

2000VA/1.28kWh

2000VA/2.56kWh

3000VA/2.56kWh
