Zeliox ECO - Page 36

Zeliox ECO
Battery
Expansion
Output voltage range
11.6~14.2VDC
11.2~14.2VDC
Battery Model
M12-100/P,
(12.8V100Ah)
M12-200/H,
(12.8V200Ah)
Discharging current
120A
175A
Terminal
Anderson SA120（
Grey）
Anderson SA175
（Grey）
Isolation guard
YES
Display
LED+3-bit digital tube+2 button
Data logging - Bluetooth
YES
Remote ON/OFF
YES
Dry
contact
output
Dry contact
1
Engine start
30VDC/2A
Dry contact
2
D+
Simulation
30VDC/2A
Dry contact
3
Distribution
30VDC/2A
Self-discharge rate per month
< 3%
Operating mode self consumption
15W
Sleep mode consumption
<0.1mA
Operating cell
temperature
Charge
2℃~60℃
Discharge
-20℃~60℃
Storage Temperature Range
-20℃~45℃（Less than 1 month），
<70% RH
0℃~35℃（Less than 1 year），<70%
RH
Cooling
Forced fan
IP rating
IP20
Product dimensions in mm
450*391.5*225
520*391.5*303
Product weight
32.6kg
34.8kg
50.6 kg
53.8 kg
Package dimensions in mm
525*485*305
595*485*385
Package weight
36kg
38.2kg
54.6 kg
57.8 kg
Table 8-1 Specifications Zeliox ECO
36
