Power supply:
C omponent video R (yellow)
Component video G (white)
Component video B (red)
Ground video (black)
Not used
Ground video (black)
Ground audio (black)
Video out CVBS (yellow)
Audio output L (white)
Audio output R (red)
Not used
Not used
IR data (blue)
IR LED (green)
IR power (brown)
Ground/GND (black)
Connect to the chassis or metallic body of the car.
+12/24 V (yellow)
Connect to a permanent +12/24 V power supply.
ACC (red)
Connect to a ignition switched +12/24 V power supply.
Front and rear side:
Power/AV/IR port
Antenna input
Status LED
USB port
Reset button
NOTE:
■ Depending on which wiring harness you are using, the pin contacts are
not fully used.
