COMPONENT PARTS LIST
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
CM151 4-14 CA - COMPONENTS
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
SEE REFERENCE CHART ON PAGE 4-12
FGIPQRSXYZ C1426 022-08188-05A CAP, 10 MFD 20% 25V,
NONPLZD ELECTROLYTIC
BCDEFGHIJKLMNOPQRSTUVWXYZa C1427 022-08188-05A CAP, 10 MFD 20% 25V,
NONPLZD ELECTROLYTIC
BCDEFGHIJKLMNOPQRSTUVWXYZa C1428 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
BCDEHJKLMNOTUVWa C1429 022-08312-05A CAP, 2.2 MFD 20% 50V,
ELECTRO
BCDEFGHIJKLMNOPQRSTUVWXYZa C1430 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
FGIPQRSXYZ C1431M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
FGIPQRSXYZ C1432 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
BCDEFGHIJKLMNOPQRSTUVWXYZa C1433M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
BCDEFGHIJKLMNOPQRSTUVWXYZa C1436 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
BCDEHJKLMNOTUVWa C1437 022-08312-05A CAP, 2.2 MFD 20% 50V,
ELECTRO
BCDEHJKLMNOTUVWa C1438 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
BCDEHJKLMNOTUVWa C1439 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
FGIPQRSXYZ C1440 022-08309-14A CAP, 330 MFD 20% 16V,
ELECTRO
FGIPQRSXYZ C1441M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
FGIPQRSXYZ C1442 022-08309-11A CAP, 47 MFD 20% 16V,
ELECTRO
FGIPQRSXYZ C1443 022-08312-03A CAP, 0.47 MFD 20% 50V,
ELECTRO
FGIPQRSXYZ C1444M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
FGIPQRSXYZ C1445 022-08309-11A CAP, 47 MFD 20% 16V,
ELECTRO
FGIPQRSXYZ C1446 022-08312-03A CAP, 0.47 MFD 20% 50V,
ELECTRO
DEHLMNOTUVW C1455 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
DEHLMNOTUVW C1456 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2101 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2102 022-08049-24A CAP, 0.10 MFD 10% 50V,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2103 022-08049-24A CAP, 0.10 MFD 10% 50V,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2104 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2106 022-08049-24A CAP, 0.10 MFD 10% 50V,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2108 022-08310-11A CAP, 47 MFD 20% 25V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2109 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2111 022-07786C CAP, 1000 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2112 022-07786-10C CAP, 470 PFD 10% 500V,
CERAMIC DISC
ABCDEFGIJKLMNOPQRSZa C2201M 063-11059-09A RESISTOR, THICK FILM CHIP,
22 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2202M 022-08352-14A CAP, 12 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2203 022-08312A CAP, 0.1 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2204 022-08312A CAP, 0.1 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2205 022-08312A CAP, 0.1 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2206M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2207 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2208 022-08312-05A CAP, 2.2 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2209 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2210M 022-08370-24A CAP, 22,000 PFD 10% 16V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2213M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2214M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2215M 022-08366-04A CAP, 470 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2216 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2217M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2218 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2219 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2220 022-08049-24A CAP, 0.10 MFD 10% 50V,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2221 022-08312A CAP, 0.1 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2222 022-08312A CAP, 0.1 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2223 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2224 022-08492-01A CAP, 1 MFD 20% 50V,
NONPLZD ELECTROLYTIC
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2225 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2226 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
FGIPQRSXYZ C2227 022-08310-11A CAP, 47 MFD 20% 25V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2229M 022-08354-41A CAP, 160 PFD 5% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2230 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2231 022-08049-24A CAP, 0.10 MFD 10% 50V,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2232M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2235M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2236M 022-08366A CAP, 220 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2237M 022-08366A CAP, 220 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2238M 022-08366-08A CAP, 1,000 PFD 10% 50V,
CERAMIC CHIP, LDLESS
HTUVWXY C2239 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C2241 022-08310-10A CAP, 33 MFD 20% 25V,
ELECTRO
HTUVW C2242M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGIJKLMNOPQRSZa C2242M 022-08352-38A CAP, 120 PFD 5% 50V,
CERAMIC CHIP, LDLESS
MOQSUWa C2254 022-07786-11C CAP, 560 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLNPRTVXYZ C2254 022-08048-01A CAP, 0.0012 MFD 5% 50V,
POLYESTER
HTUVWXY C2501M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC
CHIP, LDLESS
HTUVWXY C2502 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
