COMPONENT PARTS LIST
RC REF PART# DESCRIPTION
CM151 4-15 CA - COMPONENTS
RC REF PART# DESCRIPTION
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
SEE REFERENCE CHART ON PAGE 4-128
HTUVWXY C2504 022-08309-11A CAP, 47 MFD 20% 16V,
ELECTRO
HTUVWXY C2505 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
HTUVWXY C2506 022-08309-11A CAP, 47 MFD 20% 16V,
ELECTRO
HTUVWXY C2507M 022-08366-20 CAP, 10,000 PFD 10% 50V,
CERAMIC CHIP, LDLESS
HTUVWXY C2508 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
HTUVWXY C2509M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
HTUVWXY C2510M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
HTUVWXY C2511 022-08312A CAP, 0.1 MFD 20% 50V,
ELECTRO
HTUVWXY C2512M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
HTUVWXY C2513 022-08312-01A CAP, 0.22 MFD 20% 50V,
ELECTRO
HTUVWXY C2514M 022-08366-20 CAP, 10,000 PFD 10% 50V,
CERAMIC CHIP, LDLESS
HTUVWXY C2515 022-08310-11A CAP, 47 MFD 20% 25V,
ELECTRO
HTUVWXY C2516M 022-08366-28 CAP, 47,000 PFD 10% 50V,
CERAMIC CHIP, LDLESS
HTUVWXY C2517 022-08312-01A CAP, 0.22 MFD 20% 50V,
ELECTRO
HTUVWXY C2518M 022-08352-14A CAP, 12 PFD 5% 50V, CERAMIC
CHIP, LDLESS
HTUVWXY C2519M 022-08352-38A CAP, 120 PFD 5% 50V,
CERAMIC CHIP, LDLESS
HTUVWXY C2520M 022-08366A CAP, 220 PFD 10% 50V,
CERAMIC CHIP, LDLESS
HTUVWXY C2521M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
HTUVWXY C2522M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
HTUVWXY C2524 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
HTUVWXY C2526 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
HTUVWXY C2527 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
HTUVWXY C2529M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
HTUVWXY C2530 022-08312-03A CAP, 0.47 MFD 20% 50V,
ELECTRO
HTUVWXY C2531 022-08048-01A CAP, 0.0012 MFD 5% 50V,
POLYESTER
HTUVWXY C2532 022-08247-46A CAP, 330 PFD 5% 50V,
CERAMIC DISC
HTUVWXY C2534M 022-08366-08A CAP, 1,000 PFD 10% 50V,
CERAMIC CHIP, LDLESS
HTUVWXY C2536M 022-08366A CAP, 220 PFD 10% 50V,
CERAMIC CHIP, LDLESS
FGHIPQRSTUVWXYZ C2900 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
FGHIPQRSTUVWXYZ C2904 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
FGIPQRSXYZ C2906 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
FGIPQRSXYZ C2907M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
HTUVWXY C2908 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
HTUVWXY C2909 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
XY C2910 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
HTUVWXY C2911 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
XY C2912M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC
CHIP, LDLESS
XY C2913 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
XY C2914 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
XY C2916 022-08257-24A CAP, 10,000 PFD 10% 50V,
CERAMIC DISC
XY C2917M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC
CHIP, LDLESS
HTUVWXY C2918 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
FGIPQRSXYZ C2919 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C3201M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C3202 022-08257-08A CAP, 470 PFD 10% 50V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa C3203 022-08049-16A CAP, 0.022 MFD 10% 50V,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa C3204 022-07786-17C CAP, 2200 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa C3206 022-07811A CAP, 1000 PFD 10% 1000V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa C3209 022-07786-10C CAP, 470 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa C3419 022-07786-10C CAP, 470 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa C3421 022-07786-10C CAP, 470 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa C3425 022-08310-15 CAP, 470 MFD 20% 25V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C3426 022-08309-13A CAP, 220 MFD 20% 16V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C3429 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C3460 022-08310-13A CAP, 220 MFD 20% 25V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C5101 022-08318-04A CAP, 1 MFD 20% 350V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C5102M 022-08366A CAP, 220 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C5103M 022-08366A CAP, 220 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C5104 022-07523-01B CAP, 0.01 MFD +80 % & -20 %
2000V, CERAMIC DI
ABCDEFGHIJKLMNOPQRSTUVWXYZa C5105M 022-08366A CAP, 220 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C5106M 022-08366A CAP, 220 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C5107 022-08309-13A CAP, 220 MFD 20% 16V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C5108M 022-08366A CAP, 220 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C5109M 022-08366A CAP, 220 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C5110 022-08049-24A CAP, 0.10 MFD 10% 50V,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa C5111 022-07786-10C CAP, 470 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6001M 022-08352-38A CAP, 120 PFD 5% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6003M 022-08366-04A CAP, 470 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEJKa C6004 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6005M 022-08366A CAP, 220 PFD 10% 50V,
CERAMIC CHIP, LDLESS
