COMPONENT PARTS LIST
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
CM151 4-16 CA - COMPONENTS
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
SEE REFERENCE CHART ON PAGE 4-12
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6006 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6007M 022-08366-08A CAP, 1,000 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6009 022-08049-24A CAP, 0.10 MFD 10% 50V,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6010M 022-08352-19A CAP, 20 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6011M 022-08352-19A CAP, 20 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6012M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6013 022-08309-13A CAP, 220 MFD 20% 16V,
ELECTRO
ABCDEJKLMNOa C6014M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC
CHIP, LDLESS
FGHIPQRSTUVWXYZ C6014M 022-08352-32A CAP, 68 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEJKLMNOa C6015M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC
CHIP, LDLESS
FGHIPQRSTUVWXYZ C6015M 022-08352-32A CAP, 68 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6016 022-08312-05A CAP, 2.2 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6017 022-08049-24A CAP, 0.10 MFD 10% 50V,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6018M 022-08366-12A CAP, 2,200 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6019M 022-08366-04A CAP, 470 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6020 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6021M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGIJKLMNOPQRSXYZa C6023M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
HTUVW C6023M 022-08354-41A CAP, 160 PFD 5% 50V, CERAMIC
CHIP, LDLESS
CEGKNORSVWY C6026M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6028 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6029M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
CEGKNORSVWY C6030 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
ABDFHIJLMPQTUXZa C6030 022-08309-16 CAP, 1000 MFD 20% 16V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6031M 022-08366-12A CAP, 2,200 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6032 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO
FGGILMNOPQRSTUVWXYZ C6036M 022-08366-08A CAP, 1,000 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6037 022-08257-04A CAP, 220 PFD 10% 50V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6038M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6040M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6041M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6042M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6043M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6045M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6046M 022-08366-04A CAP, 470 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6047M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6048M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6049M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6050M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6051M 022-08354-41A CAP, 160 PFD 5% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6052M 022-08354-41A CAP, 160 PFD 5% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6053M 022-08354-41A CAP, 160 PFD 5% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6055M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6056M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6058M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6061M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
XY C6064M 022-08366A CAP, 220 PFD 10% 50V,
CERAMIC CHIP, LDLESS
XY C6065M 022-08352-19A CAP, 20 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6068M 022-08366-12A CAP, 2,200 PFD 10% 50V,
CERAMIC CHIP, LDLESS
CEGKNORSVWY C6069M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
CEGKNORSVWY C6070M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6079M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6090M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6092M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6093M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6094M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6095M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C6098 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa CR2201 224-00027A CRYSTAL, QUARTZ, 3.579 MHZ
ABCDEFGHIJKLMNOPQRSTUVWXYZa CR2202 224-00178 RESONATOR, CERAMIC, 503
KHZ
HTUVWXY CR2501 224-00061-04 CRYSTAL, QUARTZ, 14.31818
MHZ
ABCDEFGHIJKLMNOPQRSTUVWXYZa CRT0001 078-03394-09 SOCKET, CRT
ABCDEFGHIJKLMNOPQRSTUVWXYZa CRY6001 224-00074-02A CRYSTAL, QUARTZ, 8 MHZ
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX2105 022-08311-13 CAP, 220 MFD 20% 35V,
ELECTRO
XY CX2107 022-08310-16 CAP, 1000 MFD 20% 25V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWZa CX2107 022-08310-17 CAP, 2200 MFD 20% 25V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX2110 022-08311-12A CAP, 100 MFD 20% 35V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3003 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3004 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3007 022-07786-10C CAP, 470 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3205 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3207A 022-08159 CAP, 0.68 MFD 10% 200V,
POLYESTER
