Zenoah G230RC User Manual

Model Name & Cord
Key# Part Number Description Q'ty
GR23101 GR23102 GR23103 GR23104 Remarks
G230RC G230RC1 G230RC2 G230RC3
10. Parts list
13
1 T2070-12110 CYLINDER 1 ●●●●
2 T2070-12210 GASKET 1 ●●●●
3 01252-30522 BOLT 2 ●●●●M5x22L
4 1148-13161 INSULATOR 1 ●●●●
5 1140-13151 GASKET, INSU 1 ●●●●
6 3330-14121 GASKET, CARB 1 ●●●●
7 0263-90520 SCREW 2 ●●●●M5x20L
8 T2070-15110 MUFFLER 1 ●● ––
9 01252-30550 BOLT 2 ●● – – M5x50L
10 1140-13141 GASKET, MUFFLER 1 ●●●●
11 1850-32160 SCREW 1 ●● – – M4x12L
12 T2070-21101 CRANKCASE-C 1 ●●●●
13 2629-21130 • PIN 3 ●●●●
14 5500-21141 GASKET, CASE 1 ●●●●
15 1155-21240 BEARING 2 ●●●●
16 2169-21210 SEAL 1 ●●●●
17 1850-21220 SEAL 1 ●●●●
18 04065-02812 RING 1 ●●●●
19 01252-30530 BOLT 4 ●●●●M5x30L
20 T2070-41110 PISTON 1 ●●●●
21 T2070-41210 RING 1 ●●●●
22 1101-41310 PIN 1 ●●●●
23 1260-41320 RING 2 ●●●●
24 5500-41410 BEARING 1 ●●●●
25 1101-41340 WASHER 2 ●●●●
26 T2070-42000 CRANKSHAFT-C 1 ●●●●
27 1650-43230 NUT 1 ●●●●M8x1.0
28 1000-43240 KEY 1 ●●●●
29 1140-43250 SIM 1 ●●●●
30 1140-51111 SHOE 2 ●●● –
31 T2070-51220 SPRING 1 ●●●– (6000rpm IN)
32 1140-51250 SCREW 2 ●●● – M6x22L
33 1140-51230 WASHER 2 ●●● –
34 1140-51242 WASHER 2 ●●● –
35 1140-21162 CASE, CLUTCH 1 ●●● –
36 3350-15250 BOLT 4 ●●● – M5x16L
37 1140-55310 PLATE 1 ●●● –
38 0224-30614 BOLT 1 ●●● – M6x14L
39 T2070-71110 ROTOR 1 ●●●●
40 T2070-71200 COIL-A 1 ●●●●
42 T2070-72210 CAP 1 ●●●●
43 1400-72121 SPRING 1 ●●●●
44 5500-72130 GROMMET 1 ●●●●
45 1260-71261 SPACER 2 ●●●●
46 3350-14150 BOLT 2 ●●●●M4x20L
47 T2070-75101 RECOIL-A 1 ●●●●
48 T2070-75110 • CASE 1 ●●●●
49 5990-75120 • SPRING, SPIRAL 1 ●●●●
50 5990-75131 • REEL 1 ●●●●
51 5990-75141 • RATCHET 1 ●●●●
52 5990-75151 • SPRING, BREAK 1 ●●●●
53 5990-75270 • SCREW 1 ●●●●
54 5990-75160 • RETAINER 1 ●●●●
55 5990-75170 • WASHER 1 ●●●●
56 1861-75180 • ROPE 1 ●●●●
57 1490-75181 • KNOB 1 ●●●●
58 0263-90416 SCREW 4 ●●●●M4x16L
59 T2070-81000 CARBURETOR-A 1 ●●●●WT-603
60 3306-81380 • SCREEN 1 ●●●●
61 3080-81120 • COVER 1 ●●●●
62 3310-81130 • SCREW 1 ●●●●
63 3304-81140 • GASKET 1 ●●●●
64 1172-81150 • DIAPHRAGM 1 ●●●●
65 1751-81470 • GASKET 1 ●●●●
