Zenoah G230RC User Manual

10. Parts list
14
Model Name & Cord
Key# Part Number Description Q'ty
GR23101 GR23102 GR23103 GR23104 Remarks
G230RC G230RC1 G230RC2 G230RC3
66 3310-81260 • DIAPHRAGM 1 ●●●●
67 T2070-81210 • BODY-A 1 ●●●●
68 1751-81520 • COVER 1 ●●●●
69 1751-81510 • PUMP 1 ●●●●
70 2867-81270 • SPRING 1 ●●●●
71 3356-81310 • VALVE inlet 1 ●●●●
72 1480-81420 • PLUG welch 1 ●●●●
73 3310-81230 • LEVER 1 ●●●●
74 3310-81240 • SCREW 1 ●●●●
75 3310-81250 • PIN 1 ●●●●
76 2630-81330 • SCREW 1 ●●●●
77 3350-81380 • SPRING 1 ●●●●
78 T2070-81370 • SHAFT throttle 1 ●●●●
79 2670-81410 • SPRING 1 ●●●●
80 2880-81470 • SCREW 2 ●●●●
81 3310-81340 • VALVE throttle 1 ●●●●
82 3310-81360 • SCREW 1 ●●●●
83 1790-81440 • LEVER throttle 1 ●●●●
84 1148-81390 • RING 1 ●●●●
85 T2070-81460 • SHAFT choke 1 ●●●●
86 2670-81450 • VALVE choke 1 ●●●●
87 3350-81350 • SPRING 1 ●●●●
88 3350-81220 • BALL 1 ●●●●
89 1148-81530 • SCREW 4 ●●●●
90 1491-81160 • SPRING 1 ●●●●
91 1148-81171 • NEEDLE low speed 1 ●●●●
92 3080-81320 • SPRING 1 ●●●●
93 T2070-81330 • NEEDLE high speed 1 ●●●●
94 3304-81450 • SCREEN 1 ●●●●
95 3304-81441 • RING 1 ●●●●
96 3360-81440 • PLUG 1 ●●●●
98 T2070-82410 LEVER 1 ●●●●
99 T2070-82510 SPACER 1 ●●●●
100 0263-90560 SCREW 2 ●● – – M5x60L
101 0263-90550 SCREW 2 – – ●●M5x50L
102 T2070-82000 CLEANER-A 1 ●● ––
103 5731-82011 • HOUSING 1 ●● ––
104 5730-82040 • COVER 1 ●● ––
105 1750-82020 • FILTER 1 ●● ––
106 5730-82060 • SLEEVE 2 ●● ––
107 T2070-31110 COVER, FAN 1 ●●●●
108 3310-12281 BOLT 4 ●●●●M5x20L
109 T2070-32100 COVER-A 1 ●●●●
110 1850-32160 SCREW 1 ●●●●M4x12L
111 1900-31410 SCREW 2 ●●●●TP4.5x18L
112 T1108-73110 SPARKPLUG 1 ●●●●
113 T2070-72200 SWITCH-A 1 ●●●●
114 T2070-75410 LABEL, RECOIL 1 ● – ●●
115 T2071-75410 LABEL, RECOIL 1 – ● ––
116 1726-85004 TANK-A 1 – ● ––
117 5601-85201 • CAP-A 1 – ● ––
118 1726-85601 • PIPE COMP 1 – ● ––
119 5500-85400 • FILTER 1 – ● ––
120 1260-85460 • CLIP 1 – ● ––
121 1799-85400 PIPE COMP 1 ● – ●●
122 5500-85400 FILTER 1 ● – ●●
123 1260-85460 CLIP 1 ● – ●●
124 T3039-91310 SOCKET 1 ●●●●
125 T2070-93110 MANUAL 1 ●●●●
126 2890-96100 PULLER-A 1 ●●●●OP
127 4810-96220 STOPPER 1 ●●●●OP
128 T2070-98100 SPARKPLUG 1 ●●●●OP
(NGK CR8HVX with Terminal Nut)
129 1764-51220 SPRING 1 ●●●– OP (5000rpm IN)
