To prepare your product for long-term
storage
1. Empty the fuel tank and chain oil tank in a well
ventilated area.
2. Store the fuel in approved cans in a safe place.
3. When using vegetable based saw chain oil,
dismantle and clean the saw chain and the groove in
the bar.
CAUTION: If you do not dismantle and
clean the saw chain and the groove in
the bar, there is a risk of the saw chain
oil oxidizing. This causes the saw chain
to get stiff and the bar tip sprocket to
become jammed.
4. Fit the guide bar cover.
5. Clean the product. See instructions under
Maintenance schedule on page 30
.
6. Make sure that a complete service is carried out.
Technical data
Technical data
GZ3500T
Engine
Cylinder displacement, cm3 35,2
Cylinder bore, mm 40
Stroke, mm 28
Idle speed, rpm 2900
Power, kW/hp @ rpm 1,8/2,4 @ 10 000
Ignition system
1
Spark plug NGK CMR6H
Electrode gap, mm 0,65
Fuel and lubrication system
Fuel tank capacity, litre/cm
3
0,25/250
Oil pump capacity at 8,000 rpm, ml/min 3-9
Oil tank capacity, litre/cm
3
0,17/170
Type of oil pump Adjustable
Weight
Chainsaw without guide bar, saw chain and with empty
tanks, kg
3,4
Noise emissions
2
Sound power level, measured dB(A) 112
Sound power level, guaranteed L
WA
dB(A) 114
1
Always use the recommended spark plug type! Use of the wrong spark plug can damage the piston/cylinder.
2
Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC directive
2000/14/EC.
308 - 004 - 27.09.2017 33
