GZ3500T
Sound levels
3
Equivalent sound pressure level at the operator’s ear,
dB(A)
102
Equivalent vibration levels, a
hveq
4
Front handle, m/s
2
3,4
Rear handle, m/s
2
2,8
Saw chain/guide bar
Recommended bar lengths, inch/cm 14/36
Usable cutting length, inch/cm
13/33
Pitch, inch/mm 3/8 /9,52
Thickness of drive links, inch/mm 0,050/1,3
Type of drive sprocket/number of teeth Spur/6
Saw chain speed at 133% of maximum engine power
speed, m/s.
25,3
Accessories
Recommended cutting equipment
Chainsaw model
Zenoah GZ3500T has been evaluated
for safety according to EN-ISO 11681-2 (Machinery for
forestry - Portable chainsaw safety requirements and
testing) and fulfills the safety requirements when
equipped with the below listed guide bar and saw chain
combination(s).
Low kickback saw chain
A saw chain that is designated as Low kickback saw
chain, meets the low kickback requirement specified in
ANSI B175.1-2012.
Kickback and guide bar nose radius
For sprocket nose bars the nose radius is defined by the
number of teeth (for example 10T). For solid guide bars
the nose radius is defined by the size of the nose radius.
For a given guide bar length, you may use a guide bar
with smaller nose radius than listed.
Guide bar Saw chain
Length, inch Pitch, inch Gauge, mm Max. nose ra-
dius
Type Length, drive
links (no.)
Low Kickback
14 3/8 mini 1,3 7T Husqvarna
H37
52 Yes
3
Equivalent sound pressure level, according to ISO 22868, is calculated as the time-weighted energy total for
different sound pressure levels under various working conditions. Typical statistical dispersion for equivalent
sound pressure level is a standard deviation of 1 dB (A).
4
Equivalent vibration level, according to ISO 22867, is calculated as the time-weighted energy total for vibration
levels under various working conditions. Reported data for equivalent vibration level has a typical statistical
dispersion (standard deviation) of 1 m/s
2
.
34 308 - 004 - 27.09.2017
