Features & Controls
1. Bl
ower On/O
By pr
essing the blower is switched on and o. When switched on, the blower starts up on speed level 1.
ACT Verification
- Airflo
w Control Technology (ACT) allows the installer to set the maximum blower CFM to align with local
codes and r
egulations.
- T
o verify the maximum blower CFM:
- W
ith hood o, hold the button for 3-4 seconds. If number 6 displays = default max. CFM, if
number 3 displays = max. 590 CFM, and if number 2 displays = max. 390 CFM.
2. Speed Selection
- Pr
ess to decrease fan speed. 6, 5, 4, 3, 2, 1.
- If fan is on Speed 1 and is pr
essed, the fan will power o.
- Pr
ess to increase fan speed. Fan On, 1, 2, 3, 4, 5, 6.
- If hood is o and is pr
essed, the fan will turn on speed 1.
A
CT Enabled Speed Selections
- When A
CT is enabled, the number of blower speeds will be reduced as follows:
- 5
90 CFM = Maximum 3 speeds
- 390 CFM = Maximum 2 speeds
3
. Delay O
This featur
e is used for programmed shut down of blower 5 minutes after the function is activated. Press
once
, a dot flashes in the lower right side of display indicating the function is on. The blower will
completely shut do
wn after 5 minutes.
4
. Lights Low/High/O
Switch ligh
ts on to low by pressing once, press a second time for high and again to shut o lights.
5
. Display Window
The display windo
w indicates speed levels and features such as bae filter clean reminder, delay o and
clean air indicator
.
Lights Low/High/O
5 Min Delay O
Display (speed level, delay o, filter clean)
Adjust 6 Speed Levels
Blower On/O
1
2
3
4
5
Touch Controls
