PREPARE THE HOOD
1. Open the perimeter panels and remove the
grease filters. See Fig.10.
2. Remove the control panel unscrewing the
(4) screws 3,9x6 mm. See Fig.11.
3. Remove the (2) interiors panels unscrewing
the (8+8) screws. See Fig.12.
FIG.10
FIG.11
FIG.12
(4) MOUNTING SCREWS
(3.9 x 6 mm Flat Head)
