Milano Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Maintenance
LumiLight LED
In the unlikely event that your LumiLight LED fails, please contact Zephyr to order replacement parts.
See the list of parts and accessories page for part numbers and contact information.
LED Removal (FIG. D):
1. Remove aluminum mesh filter.
2. If applicable, remove side panels by two screws each. Remove light panel by two screws.
3. Disconnect LED light quick connector.
4. Push in the two side clips on the ends of the LED light.
5. Push LED light through the light panel opening.
Push the clip
FIG. D
Replacing Aluminum Mesh Filters
Hood Model Part Number Quantity to Order
ZOM-E30BS/ ZOM-E30BBS 50200059 2
ZOM-E36BS/ ZOM-E36BBS 50200059 2
To order parts, visit us online at http://store.zephyronline.com.
