Installation Instructions
Mounting Height, Clearance, & Ducting
24” min.
34” max.
min. A
min. B
max. C
min. D
min. E
max. F
Standard Extension
Hood Heights Duct Cover Duct Cover
minimum ducted (A) 30” 46-1/2“
minimum recirculating (B) 32” 50-1/2“
maximum (C) 42-1/2” 80”
Ceiling Heights
minimum ducted (D) 90”
(7’ 6”) 106-1/2“ (8‘ 10-1/2”)
minimum recirculating (E) 92” (7’ 8”) 110-1/2“ (9‘ 2-1/2”)
maximum (F) 112-1/2” (9’ 4-1/2“) 150” (12’ 6”)
36”
