Zephyr Siena Pro ZSP-E36BS User Manual

16
www.zephyronline.com
VOLTS HZ MAX AMPS
120 60 7
ZSP-E36BS
ZSP-E42BS
CIRCUIT DIAGRAM
MOT O R
BLUE
BROWN
GRAY
AC N
TRANS FORMER
WHITE
GRE EN
BLACK
WHITE
BODY
PURPLE
R E MAR K S :C ONDE NS E R 11+11uF 250VAC 2 FIT AC120V 60Hz
AC L
GRAY
BLUE
BROWN
BODY
GREEN
LOMID
HI
YELLOW YELLOW
YELLOW YELLOW
COM
FUSE
YELLOW
RED
WHITE
MOT O R
BODY
GREEN
YELLOW
RED
WHITE
RED RED
CONTROL
PC
GRAY
BLUE
BROWN
Wiring Diagrams
ACT 590 CFM - Fan Max. 556W @ 4.6A
ACT 390 CFM - Fan Max. 381W @ 3.4A
3RZHUFRQVXPSWLRQVKRZQIRUGHIDXOW&)0EORZHUFRQ¿JXUDWLRQ
VOLTS HZ MAX AMPS
120 60 7
ZSP-E48BS
CIRCUIT DIAGRAM
MOT O R
BLUE
BROWN
GRAY
AC N
TR ANSFOR MER
WHITE
GREE N
BLACK
WHITE
BODY
PURPLE
R E MAR K S :C ONDE NS E R 11+11uF 250VAC 2 F IT AC120V 60Hz
AC L
GRAY
BLUE
BROWN
BODY
GREEN
LO
MID
HI
YELLOW YELLOW
YELLOW YELLOW
COM
FUSE
YELLOW
RED
WHITE
MOT O R
BODY
GREEN
YELLOW
RED
WHITE
RED RED
CONTROL
PC
GRAY
BLUE
BROWN

Zephyr Siena Pro ZSP-E36BS Specifications

General

Color	stainless steel
Hood Type	wall
Venting Type	ducted, external
Temperature Sensor	no
Number of Fan Speeds	5
Duct Diameter	10 inches
Duct Length	14 1/2 inches
Control Type	button
Delay Start	yes
Interior Light	yes
Remote Control	no
Voltage	120 volts
Current	9 amperes

Weight and Dimensions

Depth	21 15/16 inches
Height	27 1/2 inches
Width	35 7/8 inches
Net Weight	62 pounds
