Zephyr Siena Pro ZSP-E36BS User Manual

1
SAFETY NOTICE ................................................................. 2-3
LIST OF MATERIALS ....................................................... 4
INSTALLATION
Ducting Calculation Sheet
....................................... 5
Mounting Height & Clearance
................................ 6
Ducting Options
........................................................... 7
+RRG6SHFL¿FDWLRQV
................................................... 8
Mounting the Range Hood
...................................... 9
FEATURES & CONTROLS
ICON Touch Controls
................................................ 10
MAINTENANCE
Cleaning, Filter Care, Part List
.............................. 11
LED Light Strip
............................................................. 12
ACT CONVERSION
..................................................................... 13
FAN CURVE DIAGRAMS
......................................................... 14-15
WIRING DIAGRAM
...................................................................... 16
TROUBLESHOOTING
................................................................ 17
WARRANTY
.................................................................................... 18
PRODUCT REGISTRATION
.................................................... 19
Table of Contents

Zephyr Siena Pro ZSP-E36BS Specifications

General

Color	stainless steel
Hood Type	wall
Venting Type	ducted, external
Temperature Sensor	no
Number of Fan Speeds	5
Duct Diameter	10 inches
Duct Length	14 1/2 inches
Control Type	button
Delay Start	yes
Interior Light	yes
Remote Control	no
Voltage	120 volts
Current	9 amperes

Weight and Dimensions

Depth	21 15/16 inches
Height	27 1/2 inches
Width	35 7/8 inches
Net Weight	62 pounds
