InstallationRequirement
System:
• Theunit is a high-pressure hydraulic system,hence all hydraulic fittings tobe ensured tight. Do nottamper with
thesefittings
• Unit is not to be kept in closed environment. Sufficient ventilation is required. Avoid any kind of high impact on
theunit
ElectricalRequirements:
• 230V+10%,5Asocketwithproperearthingtobemadeavailableatthepointofinstallation
-
• Ensure that a voltage stabilizer is installed where the mains voltage variation is more than 230V AC + 10%.
-
Alsoensureadequateearthingonvoltagestabilizer
PlumbingRequirements:
2 2
• ½”waterlinewithminimumof0.5kg/cm pressureandmaximumof2-kg/cm pressure
• Drainagelineisrequiredwithinadistanceof1meterfromtheunit
• Ballvalve&Hoseaadopter(Providedwiththeunit)
• Ensurethattherawwaterqualitymeetsthespecification
PrecautionsinInstallingTheUnit:
A. Locationoftheunit
• FindoutasuitablepositionforinstallingtheZeroBSapphire/Emeraldonthewall
• Locate the Zero B Sapphire / Emerald so as to have easy access to dispensing. Preferably with the base of the
ZeroBSapphire/Emeraldat4feetheightfromground
• ZeroBSapphire/Emeraldshouldbelocatedclosetoanavailabletaporwateroutlet(notexceeding1meterlength)
• Apre-filteralongwithinletdrainhastobelocatedoveradrainagepointsuchassinkinthekitchen
• ZeroBSapphire/Emeraldshouldbelocatedconvenientlywherethepoweroutletof230VACisavailable
• Therejectlineonthepre-filterisfreefallingwaterline,avoidconnectinganytubeoverthisport
Note:Aconstantflowfromtherejectlineduringtankfillingisanindicationofproperpurification
