19
STEP 4.
3.
Cable connections
Power
Distrbution
Box
DC Battery
GUN1/2 DC power cable(1000V)
PE
Output-Ethernet cable(shielding)
AC(L/N)
Input-Ethernet
cable(Shielding)
