174
ESSENTIAL TECHNICAL PARAMETERS
MAIN DIMENSIONS OF THE TRACTOR (MM)
Note
Contour length with a hitch device and
lowered front three-point hitch
4,708 without additional weights
Contour length with a hitch device and
without the front three-point hitch 4,067 without additional weights
Width over rear mudguards 1,890
Height to the exhaust pipe mouth 2,694 – 2,780 acc. to tyre size
Height of the tractor to the cabin upper edge 2,639 – 2,725 acc. to tyre size
Clearance under front axle beam 468 - 508 acc. to tyre size
Height of the multi-level guide in the highest
position (guide centre)
1,012 – 1,098 acc. to tyre size
Height of the rear output shaft 760 - 845 acc. to tyre size
Height of the front output shaft 636 - 806 acc. to tyre size
Wheel base 2,328
