46
GETTING TO KNOW THE TRACTOR
G154 E155 E156
LEVER OF SWITCHING ON REAR
OUTPUT SHAF DRIVE
Shifting can be carried out when the trac-
tor is in standstill by pulling up or pushing
down the lever.
a -
Independent rpm of the output
shaft drive-
- Speed depends on speed of
the engine.
n -
Neutral
b -
Dependent speed of the output
shaft speed through a gearbox.
- Speed depends on the en-
gaged gear.
LEVER OF HAND BRAKE AND HITCH
FOR SINGLE-AXLE TRAILER
1. Hand brake lever.
2. Lever of the single-axle trailer hitch
control.
HYDRAULICS CONTROL PANEL
The hydraulics control panel (1) is lo-
cated on the right mudguard.
ADDITIONAL HYDRAULIC
DISTRIBUTOR CONTROL
The additional hydraulic distributor control
(2) is located on the upper part of the right
mudguard.
